Used 2011 Monaco CAYMAN 36PBD

Standard Features (2011)

Body Construction

• Laminated Sidewall Construction
• Smooth Gel Coat Fiberglass Exterior Walls
• 17.5” Chrome Head Exterior Mirror
• One-Piece Front Windshield
• Pull-Out Generator Tray with One-Piece Door
• Interior Height 84”
• Side-Hinged Baggage Doors, All Door Locations
• One-Piece Polyethylene Pass-Through Storage Compartments
• Deluxe Full-Body Paint
• 3M Film Front Mask
• Rear Ladder
• Full-Length Mud Flap

Chassis, Engine & Suspension

• Roadmaster Raised Rail Chassis RR4R
• Cummins® ISB 340 HP Low Torque Engine with Allison® 2500 MH 6-Speed World Transmission; Torque: 660 Ibs./ ft. Max net @ 1,600 RPM; Engine Displacement: 6.7L/409 cu. in.; Rear Axle Ratio: 4.78:1 (36PFT, 36PBD)
• 7,000-lb. Hitch Receiver with Dual Connector 4-Pin or 7-Pin (36PFT, 36PBD)
• Cummins® ISC 360 HP Engine with Allison® 3000 MH 6-Speed World Transmission; Torque: 1,050 Ibs./ft. Max net @ 1,400 RPM; Engine Displacement: 8.3L/506 cu. in.; Rear Axle Ratio: 4.30:1 (40PBT, 40PBQ)
• 10,000-lb. Hitch Receiver with Dual Connector 4-Pin or 7-Pin (40PBT, 40PBQ)
• Variable Geometry Turbo Exhaust
• Engine Block Heater
• Dual Fuel Fill
• 160 Amp Alternator
• Radial Tires: 275/80R/22.5
• Cushion Air Glide Suspension with 8 Shock Absorbers and 8 Outboard- Mounted Air Bags
• Anti-Lock Braking System with Full Air Brakes
• Automatic Traction Control
• Prewire for Supplemental Braking System
• Remote Transmission Fill
• Automatic Hydraulic Leveling System

Cockpit

• Ultraleather™ Six-Way Power Pilot and Co-Pilot Seats (Co-Pilot Seat with Powered Footrest)
• In-Dash AM/FM/CD Stereo Radio with Sirius-Ready Compatibility, Aux-in-Conn, SD Card Slot and Weather Band
• Power Windshield and Manual Driver/ Passenger Solar Screens w/ Blackout Shades
• LCD 3-Camera Rear Vision System with Cameras in Exterior Mirrors
• Air Horns

Appliances and Accessories

• 12-Cubic-Foot Two-Way Four-Door Refrigerator with Ice Maker
• High-Output 2-Sealed Burner Cooktop without Oven
• Removable Solid Surface Range Covers
• Spacesaver Convection Microwave
• 32" Flatscreen LCD TV in Front Cockpit Overhead (36PBD)
• 40" Flatscreen LCD TV Midship in Living Area (N/A: 36PBD)
• 26" LCD TV with Remote in Bedroom
• Home Theater System
• Washer/Dryer Prep
• Curbside: Exterior Patio Hookups for Cable and 110V Outlet with Hatch Door to Exterior
• Digital Satellite System Prep
• Curbside: Exterior Gas Line Hook-Up Prep for LP Accessories

Interior

• Raised Panel Cabinet Doors with Hidden Hinges
• Hardwood Raised Panel Doors on Refrigerator
• Stainless Steel Kitchen Sink with Two Sink Covers
• Polished Solid Surface Kitchen Countertop with Decorative Backsplash
• Flip-Up Countertop Extension (40PBT, 40PBQ)
• Ceramic Tile in Kitchen, Living Room and Bath
• Carpeting with Pad in Bedroom
• Soft Touch Padded Vinyl Ceiling
• Wood Framed Decorative Living Area Wall Mirror (36PBD Only)
• Satin Nickel Finish Cabinetry Hardware and Bath Accessories
• Blackout Day/Night Pleated Shades in Living Area and Bedroom
• Mini Blinds in Kitchen and Bath
• Soil Repellant on Living Area Fabrics

Furniture

• Queen Bed with Overhead Cabinet and Nightstands
• Arched-Back Wood Booth Dinette with Side Sliding Dinette Table Top, Storage Access Door at End of Rear Seat Base and Drawer at Front Seat Base
• Forward Facing Seat Belts in Booth Dinette
• Roadside: Fabric Jackknife Sofa
• Roadside: Fabric Chair (36PBD, Only)
• Curbside: Fabric Jackknife Sofa (40PBT, 40PBQ)

Electrical System and Lights

• 50 Amp 120V Distribution Panel and Power Cord
• Power Control System
• 2000-Watt Inverter with Two House Batteries
• Onan® 6.0 kW Diesel Generator
• Two 12V Heavy-Duty Chassis Batteries
• Exterior Power Entry Step with Light
• Hallway Convenience Center

Plumbing and LP Systems

• Single Lever Kitchen Faucet with Pull-Out Sprayer
• Central Water Filtration System
• Demand Water System and Water Pump
• 10-Gallon LP Gas/Electric Water Heater with Electronic Ignition
• Winterization Valving System
• China Toilet with Sprayer (36PBD, 40PBQ)
• Silent Plus China Electronic Toilet (36PFT, 40PBT)
• Holding Tank Rinsing System
• Insulated Systems Compartment with Easy Access to Hook-Up
• Shower inside Wet Bay with Hot/Cold Water, Shower Head with Shut-Off
• Gravity and Pressurized Water Fill
• One-Piece Round Shower (N/A 36PBD)
• One-Piece Rectangle Shower (36PBD)

Heating Vents and Air Conditioning

• Dual 15BTU Air Conditioners with Heat Pumps and Ducted Air
• Electronic Ignition Furnace
• Kitchen Attic Fan with Wall Control
• Bath Attic Fan with Wall Control
• 12V Heater in Wet Bay

Windows Doors and Awnings

• Radius Flush-Mounted Dual Pane Safety Glass Dark Tinted Slider Windows
• Front Entry Door with Large Walk-Through, Clear Glass, Removable Screen and Anti-Skid Steps
• Eclipse Automatic Patio Awning
• Front Door Awning
• Window Awnings on All Slideout House Windows, Except Kitchen, Private Bath and Slideout Windows Under Patio Awning
• Topper Slide-Out Awnings Living Area and Bedroom
• Tinted Skylight in Bathroom with Protecta Glaze
• Roof-Mounted Awning Units with Slide-Outs Curbside at Patio Location

Safety

• Fire Extinguisher
• Deadbolt Lock on Entrance Door
• 120V GFI Protected Circuit Kitchen, Bath and Exterior
• LP Gas Detector
• Smoke Detector
• Carbon Monoxide Detector
• Driver and Passenger Three-Point Seatbelts
• Third Brake Safety Light
• Egress Window

Options

Body Construction

• Storage Bay Slide-Out Tray, Pass-Through
• Slide-Out Battery Tray Under Tanks (40PBT, 40PBQ)
• Full Chrome Exterior Mirrors

Chassis, Engine & Suspension

• Polished Aluminum Wheels

Cockpit

• Sirius Satellite Radio Tuner with Antenna
• GPS Navigation System

Appliances and Accessories

• 26" LCD TV with Remote in Cockpit Overhead (N/A: 36PBD)
• Residential Refrigerator
• Central Vacuum with Toe Kick Inlet
• Stackable Washer/Dryer
• Bedroom DVD Player
• R5 KVH In-Motion Satellite (Does Not Include Receivers; R5 HDTV for Dish Network Only)
• Multi-Satellite HD KU/KA Dish (Does Not Include Receiver)
• Exterior Sidewall Entertainment Center with 40" LCD TV with Single DVD Player in Storage Bay Ceiling
• Winegard Stationary Dish-Star(Canada Only)

Interior

• Décors: Island Style III, Mystic Moon and Tropical Paradise II
• Manual Solar Screens with Blackouts Throughout
• Wood: Newport Cherry and Glazed Newport Cherry

Furniture

• Queen Bed Select Comfort Air Mattress
• King Bed
• King Bed Premiere Select Comfort Air Mattress
• Roadside: UltraLeather Jackknife Sofa
• Roadside: Fabric Sofa Bed with Air Mattress
• Roadside: UltraLeather Sofa Bed with Air Mattress
• Roadside: UltraLeather Ensemble Booth Dinette w/ Sofa Bed (N/A: 36PFT)
• Roadside: Two Leather Euro-Recliners with Table (40PBQ Only)
• Curbside: UltraLeather Jackknife Sofa (40PBT, 40PBQ)
• Curbside: UltraLeather Sofa Bed with Air Mattress (40PBQ Only)
• Curbside: UltraLeather Sofa Bed with Removable Arms (40PBT Only)
• Hallway Bunks w/ Two Fold-Down DVD Players with Game Hookups, Wireless Headphones and Light at Each Bunk Location; Bunk Ladder (40PBT Only)
• UltraLeather Booth Dinette Sectional (36PFT Only)
• Free-Standing Dinette with Computer Workstation (N/A: 36PFT)
• Free-Standing Dinette w/ Two Free-Standing Chairs and Two Folding Chairs (N/A: 36PFT)

Electrical System and Lights

• Storage Compartment Tank Monitor Gauge
• Auto Generator Start
• 10 kW Quiet Diesel Generator (40PBT, 40PBQ)

Plumbing and LP Systems

• RV Sani-Con 1 System — Holding Tank Flush System

Heating Vents and Air Condition

• Three 15M BTU Air Conditioners w/ Heat Pumps and Ducted Air (40PBT, 40PBQ)
• Ceiling Fan in Bedroom

See us for a complete list of features and available options.

All features and specifications are subject to change.
